Soken Push Button Switch PS25-16-3
Specification Rating 16A 250VAC (TUV) Operating temperature -25~125ºC Contact resistance 100mΩ Max Insulation resistance 100mΩ Min Electrical life 10000cycles(16A 250VAC) Applicable standard IEC61058-1 Material list Contact leg Brass T=0.8mm Contact Silver alloy Terminals Brass T=0.8mm Case PA66 Push bar PA66 Drawing Product display Company introduction Ningbo Master Soken Electrical Co., Ltd. established in 1996, is a director member of Electrical Accessori...
|Rating||16A 250VAC (TUV)|
|Contact resistance||100mΩ Max|
|Insulation resistance||100mΩ Min|
|Electrical life||10000cycles(16A 250VAC)|
|Contact leg||Brass T=0.8mm|
